PC817 Optocoupler – Pack of 10

The PC817 Optocoupler is a 4-pin opto-isolator IC used to electrically isolate input and output signals, protecting microcontrollers and sensitive components from voltage spikes and interference. This pack of 10 is ideal for automation, power control, and microcontroller-based circuits.

Key Features:

• Opto-isolator with phototransistor output

• Input: IR LED; Output: NPN Phototransistor

• Isolation Voltage: 5,000 Vrms

• Compact 4-pin DIP package

• Compatible with Arduino, ESP32, Raspberry Pi

• Perfect for logic level shifting, relay driving, and industrial automation

Specifications:

• Model: PC817

• Input Current: 20 mA (typical)

• Collector-Emitter Voltage: 35V max

• CTR: 50% to 600%

• Pack Quantity: 10 pieces

Package Includes:

10 x PC817 Optocoupler – Signal Isolation Component for Microcontroller Circuits
